Introducing our V Grooving Machine for Cardboard, designed for precise grooving of gift boxes, wine boxes, and paperboard materials. Made of welded steel and sheet metal, the machine is both beautiful and durable. It features scoring capabilities as well as cutting functions, ensuring high precision with every operation. With its user-friendly design, the machine simplifies the slotting process, making it an effective solution for your packaging needs.

Parameter Specification
Model ZS-PKC1
Working Principle Electric & Air Pump
Grooving Outline 0–670 mm
Grooving Thickness 1–5 mm
Grooving Angle 90° / 120° / 145°
Die Cutting Length 0–80 mm
Power / Air Pressure 220V / 0.6 MPa
Machine Weight 110 kg
Machine Dimensions 1400 × 450 × 970 mm (L×W×H)
