ZONESUN ZS-WCHJ1 Vertical Paste Filling Machine with Heating and Mixing
DESCRIPTION
The ZS-WCHJ1 filling machine combines heating, mixing, and filling capabilities in one compact vertical unit—ideal for thick liquids, pastes, and lotions. Featuring a 35L hopper with integrated agitation and a water circulation heating system, it ensures smooth, consistent output. Whether operated by pedal or automatic mode, it’s engineered for precision and user convenience, making it perfect for small to medium-scale cosmetic and food production lines.
Parameter
Machine Model ZS-WCHJ1
Voltage 110V/220V, 50/60Hz
Power 3.2kW
Filling Speed Approx. 10–20 bottles/min (varies by material and bottle size)
Filling Range 100–1000ml (Customizable)
Filling Accuracy ±1%
Hopper Capacity 35L
Heating Temperature 0–100°C
Mixing Speed 0–35 rpm
Air Consumption 0.05m³/min
Machine Material Stainless Steel
Machine Size (L×W×H) Approx. 695 × 645 × 1760mm
Package Size (L×W×H) Approx. 770 × 630 × 1930mm
Gross Weight Approx. 129kg
Machine Model ZS-WCHJ1
Voltage 110V/220V, 50/60Hz
Power 3.2kW
Filling Speed Approx. 10–20 bottles/min (varies by material and bottle size)
Filling Range 100–1000ml (Customizable)
Filling Accuracy ±1%
Hopper Capacity 35L
Heating Temperature 0–100°C
Mixing Speed 0–35 rpm
Air Consumption 0.05m³/min
Machine Material Stainless Steel
Machine Size (L×W×H) Approx. 695 × 645 × 1760mm
Package Size (L×W×H) Approx. 770 × 630 × 1930mm
Gross Weight Approx. 129kg
DESCRIPTION
The ZS-WCHJ1 filling machine combines heating, mixing, and filling capabilities in one compact vertical unit—ideal for thick liquids, pastes, and lotions. Featuring a 35L hopper with integrated agitation and a water circulation heating system, it ensures smooth, consistent output. Whether operated by pedal or automatic mode, it’s engineered for precision and user convenience, making it perfect for small to medium-scale cosmetic and food production lines.
Parameter
Machine Model ZS-WCHJ1
Voltage 110V/220V, 50/60Hz
Power 3.2kW
Filling Speed Approx. 10–20 bottles/min (varies by material and bottle size)
Filling Range 100–1000ml (Customizable)
Filling Accuracy ±1%
Hopper Capacity 35L
Heating Temperature 0–100°C
Mixing Speed 0–35 rpm
Air Consumption 0.05m³/min
Machine Material Stainless Steel
Machine Size (L×W×H) Approx. 695 × 645 × 1760mm
Package Size (L×W×H) Approx. 770 × 630 × 1930mm
Gross Weight Approx. 129kg
Machine Model ZS-WCHJ1
Voltage 110V/220V, 50/60Hz
Power 3.2kW
Filling Speed Approx. 10–20 bottles/min (varies by material and bottle size)
Filling Range 100–1000ml (Customizable)
Filling Accuracy ±1%
Hopper Capacity 35L
Heating Temperature 0–100°C
Mixing Speed 0–35 rpm
Air Consumption 0.05m³/min
Machine Material Stainless Steel
Machine Size (L×W×H) Approx. 695 × 645 × 1760mm
Package Size (L×W×H) Approx. 770 × 630 × 1930mm
Gross Weight Approx. 129kg
Select Filling Capacity
Select Voltage
From $479.70
Original: $1,599.00
-70%ZONESUN ZS-WCHJ1 Vertical Paste Filling Machine with Heating and Mixing—
$1,599.00
$479.70Description
