ZONESUN ZS-GTFS2 Semi-Auto Piston Filling Machine for Thick Liquids & Pastes
Introducing our innovative piston filler, designed for effortless and precise filling of viscous liquids and pastes. This versatile machine features a sturdy stand base, eliminating the need for a separate table. Its semi-automatic operation allows for easy and efficient filling, simply place your container on the filling platform and let the piston do the work. The large U-shaped hopper ensures a consistent supply of material, while the adjustable filling volume caters to your specific needs. Experience the convenience and accuracy of our piston filler, perfect for a wide range of applications.
Parameter
Model ZS-GTFS2
Voltage 220V/110V, 50–60Hz
Machine Power Approx. 2130 W
Filling Pump Piston Pump
Filling Range 10–100 / 10–200 / 30–300 / 50–500 / 100–1000 / 500–2500 / 1000–5000 ml
Filling Speed Approx. 12–20 bottles/min
Filling Accuracy ≤ ±1%
Hopper Capacity 90 L
Air Pressure 0.4–0.6 MPa
Hopper Package Size Approx. 1020 × 570 × 610 mm
Filling Machine Size Approx. 1360 × 570 × 1060 mm (for 1000 ml model)
Hopper Gross Weight Approx. 55 kg
Filling Machine Weight Approx. 90 kg
Introducing our innovative piston filler, designed for effortless and precise filling of viscous liquids and pastes. This versatile machine features a sturdy stand base, eliminating the need for a separate table. Its semi-automatic operation allows for easy and efficient filling, simply place your container on the filling platform and let the piston do the work. The large U-shaped hopper ensures a consistent supply of material, while the adjustable filling volume caters to your specific needs. Experience the convenience and accuracy of our piston filler, perfect for a wide range of applications.
Parameter
Model ZS-GTFS2
Voltage 220V/110V, 50–60Hz
Machine Power Approx. 2130 W
Filling Pump Piston Pump
Filling Range 10–100 / 10–200 / 30–300 / 50–500 / 100–1000 / 500–2500 / 1000–5000 ml
Filling Speed Approx. 12–20 bottles/min
Filling Accuracy ≤ ±1%
Hopper Capacity 90 L
Air Pressure 0.4–0.6 MPa
Hopper Package Size Approx. 1020 × 570 × 610 mm
Filling Machine Size Approx. 1360 × 570 × 1060 mm (for 1000 ml model)
Hopper Gross Weight Approx. 55 kg
Filling Machine Weight Approx. 90 kg
Description
Introducing our innovative piston filler, designed for effortless and precise filling of viscous liquids and pastes. This versatile machine features a sturdy stand base, eliminating the need for a separate table. Its semi-automatic operation allows for easy and efficient filling, simply place your container on the filling platform and let the piston do the work. The large U-shaped hopper ensures a consistent supply of material, while the adjustable filling volume caters to your specific needs. Experience the convenience and accuracy of our piston filler, perfect for a wide range of applications.
Parameter
Model ZS-GTFS2
Voltage 220V/110V, 50–60Hz
Machine Power Approx. 2130 W
Filling Pump Piston Pump
Filling Range 10–100 / 10–200 / 30–300 / 50–500 / 100–1000 / 500–2500 / 1000–5000 ml
Filling Speed Approx. 12–20 bottles/min
Filling Accuracy ≤ ±1%
Hopper Capacity 90 L
Air Pressure 0.4–0.6 MPa
Hopper Package Size Approx. 1020 × 570 × 610 mm
Filling Machine Size Approx. 1360 × 570 × 1060 mm (for 1000 ml model)
Hopper Gross Weight Approx. 55 kg
Filling Machine Weight Approx. 90 kg
