ZONESUN ZS-WGTB01 High-Speed Round Bottle Labeling Machine
The ZS-WGTB01 is a fully automatic labeling system engineered for cylindrical containers. It applies glue-based labels with precision using an application belt, ensuring consistent, high-quality results for streamlined production. Ideal for bottling lines seeking reliable and efficient label application.
Parameter Specification
Compressed Air Pressure 0.3–0.4 MPa
Power Supply 220V / 50Hz
Power Consumption 2 KW
Working Speed 40–80 bottles/min
Bottle Type Cylindrical
Bottle Size Diameter ≤ 11 cm, Height ≤ 40 cm
Max Label Size Length ≤ 33 cm, Height ≤ 15 cm
Adhesive Type Aqueous hot-melt adhesive
Machine Dimensions Approx. 3050 × 960 × 1120 mm
Packaging Dimensions Approx. 3160 × 1220 × 1500 mm
Package Weight Approx. 480 kg
The ZS-WGTB01 is a fully automatic labeling system engineered for cylindrical containers. It applies glue-based labels with precision using an application belt, ensuring consistent, high-quality results for streamlined production. Ideal for bottling lines seeking reliable and efficient label application.
Parameter Specification
Compressed Air Pressure 0.3–0.4 MPa
Power Supply 220V / 50Hz
Power Consumption 2 KW
Working Speed 40–80 bottles/min
Bottle Type Cylindrical
Bottle Size Diameter ≤ 11 cm, Height ≤ 40 cm
Max Label Size Length ≤ 33 cm, Height ≤ 15 cm
Adhesive Type Aqueous hot-melt adhesive
Machine Dimensions Approx. 3050 × 960 × 1120 mm
Packaging Dimensions Approx. 3160 × 1220 × 1500 mm
Package Weight Approx. 480 kg
Original: $8,299.00
-70%$8,299.00
$2,489.70Description
The ZS-WGTB01 is a fully automatic labeling system engineered for cylindrical containers. It applies glue-based labels with precision using an application belt, ensuring consistent, high-quality results for streamlined production. Ideal for bottling lines seeking reliable and efficient label application.
Parameter Specification
Compressed Air Pressure 0.3–0.4 MPa
Power Supply 220V / 50Hz
Power Consumption 2 KW
Working Speed 40–80 bottles/min
Bottle Type Cylindrical
Bottle Size Diameter ≤ 11 cm, Height ≤ 40 cm
Max Label Size Length ≤ 33 cm, Height ≤ 15 cm
Adhesive Type Aqueous hot-melt adhesive
Machine Dimensions Approx. 3050 × 960 × 1120 mm
Packaging Dimensions Approx. 3160 × 1220 × 1500 mm
Package Weight Approx. 480 kg
