Zonesun ZS-STB150L Automatic Sleeve Labeling Machine for Bottles & Containers
Description
The ZS-STB150L is a fully automated sleeve labeling system designed to apply and shrink full-body sleeve labels or tamper-evident bands onto various container types and shapes, including round, square, oval, and contoured bottles. It features precise sleeve positioning and advanced shrinking capabilities that enhance the appearance and branding of each product. Equipped with an applicator, shrink tunnel(s), steam generator, and stainless steel conveyor, this machine ensures seamless integration into your packaging line.
Parameter
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
Description
The ZS-STB150L is a fully automated sleeve labeling system designed to apply and shrink full-body sleeve labels or tamper-evident bands onto various container types and shapes, including round, square, oval, and contoured bottles. It features precise sleeve positioning and advanced shrinking capabilities that enhance the appearance and branding of each product. Equipped with an applicator, shrink tunnel(s), steam generator, and stainless steel conveyor, this machine ensures seamless integration into your packaging line.
Parameter
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
$3,899.70
Original: $12,999.00
-70%Zonesun ZS-STB150L Automatic Sleeve Labeling Machine for Bottles & Containers—
$12,999.00
$3,899.70Description
Description
The ZS-STB150L is a fully automated sleeve labeling system designed to apply and shrink full-body sleeve labels or tamper-evident bands onto various container types and shapes, including round, square, oval, and contoured bottles. It features precise sleeve positioning and advanced shrinking capabilities that enhance the appearance and branding of each product. Equipped with an applicator, shrink tunnel(s), steam generator, and stainless steel conveyor, this machine ensures seamless integration into your packaging line.
Parameter
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
Machine Model ZS-STB150
Bottle Diameter Range Φ28mm–Φ125mm (customizable)
Bottle Height 30mm–280mm (customizable)
Label Length 30mm–250mm (customizable)
Label Thickness 0.03mm–0.13mm (PVC, PET, OPS – all available)
Sleeve Standard Error ±1.5mm
Paper Tube Inner Diameter 5"–10" (adjustable)
Machine Speed 150 bottles/min (based on label length)
Voltage 220V, Single Phase
Power 15KW
Conveyor Belt Standard 2M
Machine Size Approx. 2950 × 1030 × 1870 mm (L × W × H)
Machine Weight Approx. 464 kg
