ZONESUN ZS-GTC1000 Milk & Juice Gable-Top Carton Filling Machine
The ZS-GTC1000 is a fully automatic gable-top carton packaging machine constructed with food-grade stainless steel. It integrates carton forming, bottom sealing, filling, capping (optional), top sealing, and date printing into one streamlined process. Ideal for dairy, juice, and beverage industries, this machine offers cost-effective, labor-saving performance with customizable carton sizes and filling volumes. ZONESUN ensures reliable automation for liquid packaging operations.
Parameter
Machine Model ZS-GTC1000
Voltage 110V / 220V
Power 15 kW
Capacity 200–1000 ml / 1000–2000 ml
Packing Material Cardboard carton / Aluminum foil carton
Filling Temperature Cold filling: 2–50°C / Hot filling: 80–92°C
Carton Packing Size Customized
Cap Without cap (optional)
Compressed Air Pressure 0.8–1.0 MPa
Flow Volume ≥20 L/min
Machine Size 160 × 120 × 180 cm
Machine Weight 500 kg
The ZS-GTC1000 is a fully automatic gable-top carton packaging machine constructed with food-grade stainless steel. It integrates carton forming, bottom sealing, filling, capping (optional), top sealing, and date printing into one streamlined process. Ideal for dairy, juice, and beverage industries, this machine offers cost-effective, labor-saving performance with customizable carton sizes and filling volumes. ZONESUN ensures reliable automation for liquid packaging operations.
Parameter
Machine Model ZS-GTC1000
Voltage 110V / 220V
Power 15 kW
Capacity 200–1000 ml / 1000–2000 ml
Packing Material Cardboard carton / Aluminum foil carton
Filling Temperature Cold filling: 2–50°C / Hot filling: 80–92°C
Carton Packing Size Customized
Cap Without cap (optional)
Compressed Air Pressure 0.8–1.0 MPa
Flow Volume ≥20 L/min
Machine Size 160 × 120 × 180 cm
Machine Weight 500 kg
Original: $44,500.00
-70%$44,500.00
$13,350.00Description
The ZS-GTC1000 is a fully automatic gable-top carton packaging machine constructed with food-grade stainless steel. It integrates carton forming, bottom sealing, filling, capping (optional), top sealing, and date printing into one streamlined process. Ideal for dairy, juice, and beverage industries, this machine offers cost-effective, labor-saving performance with customizable carton sizes and filling volumes. ZONESUN ensures reliable automation for liquid packaging operations.
Parameter
Machine Model ZS-GTC1000
Voltage 110V / 220V
Power 15 kW
Capacity 200–1000 ml / 1000–2000 ml
Packing Material Cardboard carton / Aluminum foil carton
Filling Temperature Cold filling: 2–50°C / Hot filling: 80–92°C
Carton Packing Size Customized
Cap Without cap (optional)
Compressed Air Pressure 0.8–1.0 MPa
Flow Volume ≥20 L/min
Machine Size 160 × 120 × 180 cm
Machine Weight 500 kg
