ZONEUSN ZS-TB160PO Labeling Machine with Ink-Free Thermal Printing
The ZS-TB160PO labeling machine uses advanced thermal technology to print crisp text and images without the need for ink, toner, or ribbons. Designed for fast and efficient labeling of boxes, bags, and flat surfaces, it’s perfect for short-term labeling applications where simplicity and speed matter most.
Parameter
Machine Model ZS-TB160PO
Machine Voltage 110/220V, 50–60Hz
Printing Method Thermal Transfer / Thermal Sensitive
Printing Resolution 200dpi / 300dpi
Printing Speed 2–10 inches/sec (200dpi) / 2–7 inches/sec (300dpi)
Printing Range 25–180mm (L) × 25–104mm (W)
Paper Roll Size Inner Diameter: Φ76mm; Outer Diameter: 250mm
Backing Paper Size Width: 25.4–106mm; Thickness: 0.06–0.30mm
Ribbon Size Length: 450m; Width: 25–110mm; Max OD: 90mm (Coated side faces outward)
Connection Interface USB 2.0 / Network Port
Labeling Speed 10–30 pcs/min
Labeling Accuracy ±1–3mm (Excludes product & label variation)
Applicable Label Width 25–104mm
Applicable Label Length 25–180mm
Printable Content Text, serial numbers, dates, graphics, 1D/2D barcodes, and other identifiers
Machine Weight Approx. 120kg
Package Size (L×W×H) Approx. 2200 × 900 × 1100mm
Package Weight Approx. 130kg
The ZS-TB160PO labeling machine uses advanced thermal technology to print crisp text and images without the need for ink, toner, or ribbons. Designed for fast and efficient labeling of boxes, bags, and flat surfaces, it’s perfect for short-term labeling applications where simplicity and speed matter most.
Parameter
Machine Model ZS-TB160PO
Machine Voltage 110/220V, 50–60Hz
Printing Method Thermal Transfer / Thermal Sensitive
Printing Resolution 200dpi / 300dpi
Printing Speed 2–10 inches/sec (200dpi) / 2–7 inches/sec (300dpi)
Printing Range 25–180mm (L) × 25–104mm (W)
Paper Roll Size Inner Diameter: Φ76mm; Outer Diameter: 250mm
Backing Paper Size Width: 25.4–106mm; Thickness: 0.06–0.30mm
Ribbon Size Length: 450m; Width: 25–110mm; Max OD: 90mm (Coated side faces outward)
Connection Interface USB 2.0 / Network Port
Labeling Speed 10–30 pcs/min
Labeling Accuracy ±1–3mm (Excludes product & label variation)
Applicable Label Width 25–104mm
Applicable Label Length 25–180mm
Printable Content Text, serial numbers, dates, graphics, 1D/2D barcodes, and other identifiers
Machine Weight Approx. 120kg
Package Size (L×W×H) Approx. 2200 × 900 × 1100mm
Package Weight Approx. 130kg
Description
The ZS-TB160PO labeling machine uses advanced thermal technology to print crisp text and images without the need for ink, toner, or ribbons. Designed for fast and efficient labeling of boxes, bags, and flat surfaces, it’s perfect for short-term labeling applications where simplicity and speed matter most.
Parameter
Machine Model ZS-TB160PO
Machine Voltage 110/220V, 50–60Hz
Printing Method Thermal Transfer / Thermal Sensitive
Printing Resolution 200dpi / 300dpi
Printing Speed 2–10 inches/sec (200dpi) / 2–7 inches/sec (300dpi)
Printing Range 25–180mm (L) × 25–104mm (W)
Paper Roll Size Inner Diameter: Φ76mm; Outer Diameter: 250mm
Backing Paper Size Width: 25.4–106mm; Thickness: 0.06–0.30mm
Ribbon Size Length: 450m; Width: 25–110mm; Max OD: 90mm (Coated side faces outward)
Connection Interface USB 2.0 / Network Port
Labeling Speed 10–30 pcs/min
Labeling Accuracy ±1–3mm (Excludes product & label variation)
Applicable Label Width 25–104mm
Applicable Label Length 25–180mm
Printable Content Text, serial numbers, dates, graphics, 1D/2D barcodes, and other identifiers
Machine Weight Approx. 120kg
Package Size (L×W×H) Approx. 2200 × 900 × 1100mm
Package Weight Approx. 130kg
