ZONEUSN ZS-AFS01 Paraffin Wax Cup Filling & Sealing Machine with Heating
The ZS-AFS01 is a custom-built filling and sealing machine designed for paraffin wax applications. It uses a mold conveyor system to transport cups and features cyclic heating for smooth, consistent filling. With dual piston nozzles and automated sealing, it’s ideal for high-efficiency production of wax-based products. Built to meet specialized packaging needs with precision and reliability.
Parameter Details
Model ZS-AFS01
Power Approx. 8 KW
Voltage 380V / 50Hz
Filling Pump Type Piston Pump
Number of Filling Heads 2
Working Speed Approx. 10–30 pieces/min (depends on liquid and volume)
Air Consumption 0.7 m³/min
Machine Dimensions Approx. 3600 × 968 × 1595 mm
Packing Dimensions Approx. 3800 × 970 × 2020 mm
Package Weight Approx. 1000 kg
PRODUCT DETAILS
CONTROL PANEL
PLC controls, color display touchscreen.
Barometer and thermostats, all-in-one.
Easy learning and user-friendly.
CUP FEEDING
Custom holder, mold conveyor design.
Smart detecting, auto feeding.
FILLING
Large hopper of 40L, interlayer heating, with a liquid level detector.
Heating wires, piston pump, diving nozzles.
FILM FEEDING
Auto-feeding, smart sensor, no waste of the film.
SEALING
Heat sealing and cutting, customizable for cups of different sizes.
Auto-erecting the finished products, labor-saving.
