ZONESUN ZS-FAL180X3 Automated Production Line Chili Sauce Ketchup Penut Butter
The ZS-FAL180X3 is a fully automated production line featuring filling, cap feeding, capping, and labeling functions in one seamless system. Designed for viscous products like chili sauce, ketchup, and peanut butter, it delivers stable, efficient, and intelligent operation. Ideal for the food, cosmetics, agriculture, and daily chemical sectors, it simplifies processing while reducing labor demands and boosting output quality.
PARAMETER
|
Filling machine |
||||
|
Model |
ZS-YT2T-2P |
ZS-YT4T-4P |
ZS-YT6T-6P |
ZS-YT8T |
|
Voltage |
110/220V 50-60HZ 800W |
|||
|
Filling Range |
5-100ml/10-300ml/50-500ml/100-1000ml/ 500-3000ml/1000-5000ml |
|||
|
Working Speed (base on water) |
10-40 bottles/ min |
20-50 bottles/ min |
30-70 bottles/ min |
40-80 bottles/ min |
|
Filling Accuracy |
≤±1% |
|||
|
Air Pressure |
0.5-0.7Mpa |
|||
|
Machine Weight |
220kg |
260kg |
300kg |
600kg |
|
Package Weight |
About 380kg (100-1000ml 4Heads) |
|||
|
Machine size |
2000* 1200* 2300mm |
2000* 1200* 2300mm |
2500* 1300* 2300mm |
2800* 1300* 2500mm |
|
Package Size |
About 1410*1220*2130mm (100-1000ml 4Heads) |
|||
|
Cap feeding machine |
|
|
Model |
ZS-SLJ1 |
|
Capacity |
60-120pcs/min |
|
Applicable Cap Size |
Customized |
|
Voltage |
AC220V 50HZ |
|
Power |
0.37KW |
|
Machine Size |
About 1300*600*2000mm |
|
Package Size |
About 2350*850*1070mm |
|
Net Weight/Gross Weight |
About 80kg/205kg |
|
Capping machine |
|
|
Model |
ZS-XG440D |
|
Working voltage |
AC220V/110V 50-60HZ |
|
Bottle height |
≤200mm |
|
Bottle caps diameter |
Customized |
|
Working speed |
20-30 bottles/minute(depending on bottle and caps) |
|
Working pressure |
0.4-0.6 MPa |
|
Conveyor size |
100mm(W)*1950mm(L) |
|
Package size |
About 2000*820*1800mm |
|
Net weight/Gross weight |
About 211kg/272kg |
|
Labeling Machine |
|
|
Model |
ZS-TB260R |
|
Power supply |
AC220V 50Hz/60Hz 1000W |
|
Working speed |
25-50 bottles/min(depends on bottle size) |
|
Labeling accuracy |
±1.0mm |
|
Applicable bottle diameter |
Φ12-100mm |
|
Applicable label size |
(L)20-300mm (H)15-150mm |
|
Label roll core diameter |
Φ76mm |
|
Label roll outer diameter |
Φ350mm |
|
Conveyor size |
112*2000mm(W) |
|
Machine size |
About (L)2000*(W)820*(H)1380(mm) |
|
Package size |
About (L)2100*(W)890*(H)1520(mm) |
|
Net weight/Gross weight |
About 180kg/About 250kg |
The ZS-FAL180X3 is a fully automated production line featuring filling, cap feeding, capping, and labeling functions in one seamless system. Designed for viscous products like chili sauce, ketchup, and peanut butter, it delivers stable, efficient, and intelligent operation. Ideal for the food, cosmetics, agriculture, and daily chemical sectors, it simplifies processing while reducing labor demands and boosting output quality.
PARAMETER
|
Filling machine |
||||
|
Model |
ZS-YT2T-2P |
ZS-YT4T-4P |
ZS-YT6T-6P |
ZS-YT8T |
|
Voltage |
110/220V 50-60HZ 800W |
|||
|
Filling Range |
5-100ml/10-300ml/50-500ml/100-1000ml/ 500-3000ml/1000-5000ml |
|||
|
Working Speed (base on water) |
10-40 bottles/ min |
20-50 bottles/ min |
30-70 bottles/ min |
40-80 bottles/ min |
|
Filling Accuracy |
≤±1% |
|||
|
Air Pressure |
0.5-0.7Mpa |
|||
|
Machine Weight |
220kg |
260kg |
300kg |
600kg |
|
Package Weight |
About 380kg (100-1000ml 4Heads) |
|||
|
Machine size |
2000* 1200* 2300mm |
2000* 1200* 2300mm |
2500* 1300* 2300mm |
2800* 1300* 2500mm |
|
Package Size |
About 1410*1220*2130mm (100-1000ml 4Heads) |
|||
|
Cap feeding machine |
|
|
Model |
ZS-SLJ1 |
|
Capacity |
60-120pcs/min |
|
Applicable Cap Size |
Customized |
|
Voltage |
AC220V 50HZ |
|
Power |
0.37KW |
|
Machine Size |
About 1300*600*2000mm |
|
Package Size |
About 2350*850*1070mm |
|
Net Weight/Gross Weight |
About 80kg/205kg |
|
Capping machine |
|
|
Model |
ZS-XG440D |
|
Working voltage |
AC220V/110V 50-60HZ |
|
Bottle height |
≤200mm |
|
Bottle caps diameter |
Customized |
|
Working speed |
20-30 bottles/minute(depending on bottle and caps) |
|
Working pressure |
0.4-0.6 MPa |
|
Conveyor size |
100mm(W)*1950mm(L) |
|
Package size |
About 2000*820*1800mm |
|
Net weight/Gross weight |
About 211kg/272kg |
|
Labeling Machine |
|
|
Model |
ZS-TB260R |
|
Power supply |
AC220V 50Hz/60Hz 1000W |
|
Working speed |
25-50 bottles/min(depends on bottle size) |
|
Labeling accuracy |
±1.0mm |
|
Applicable bottle diameter |
Φ12-100mm |
|
Applicable label size |
(L)20-300mm (H)15-150mm |
|
Label roll core diameter |
Φ76mm |
|
Label roll outer diameter |
Φ350mm |
|
Conveyor size |
112*2000mm(W) |
|
Machine size |
About (L)2000*(W)820*(H)1380(mm) |
|
Package size |
About (L)2100*(W)890*(H)1520(mm) |
|
Net weight/Gross weight |
About 180kg/About 250kg |
Original: $18,055.00
-70%$18,055.00
$5,416.50Description
The ZS-FAL180X3 is a fully automated production line featuring filling, cap feeding, capping, and labeling functions in one seamless system. Designed for viscous products like chili sauce, ketchup, and peanut butter, it delivers stable, efficient, and intelligent operation. Ideal for the food, cosmetics, agriculture, and daily chemical sectors, it simplifies processing while reducing labor demands and boosting output quality.
PARAMETER
|
Filling machine |
||||
|
Model |
ZS-YT2T-2P |
ZS-YT4T-4P |
ZS-YT6T-6P |
ZS-YT8T |
|
Voltage |
110/220V 50-60HZ 800W |
|||
|
Filling Range |
5-100ml/10-300ml/50-500ml/100-1000ml/ 500-3000ml/1000-5000ml |
|||
|
Working Speed (base on water) |
10-40 bottles/ min |
20-50 bottles/ min |
30-70 bottles/ min |
40-80 bottles/ min |
|
Filling Accuracy |
≤±1% |
|||
|
Air Pressure |
0.5-0.7Mpa |
|||
|
Machine Weight |
220kg |
260kg |
300kg |
600kg |
|
Package Weight |
About 380kg (100-1000ml 4Heads) |
|||
|
Machine size |
2000* 1200* 2300mm |
2000* 1200* 2300mm |
2500* 1300* 2300mm |
2800* 1300* 2500mm |
|
Package Size |
About 1410*1220*2130mm (100-1000ml 4Heads) |
|||
|
Cap feeding machine |
|
|
Model |
ZS-SLJ1 |
|
Capacity |
60-120pcs/min |
|
Applicable Cap Size |
Customized |
|
Voltage |
AC220V 50HZ |
|
Power |
0.37KW |
|
Machine Size |
About 1300*600*2000mm |
|
Package Size |
About 2350*850*1070mm |
|
Net Weight/Gross Weight |
About 80kg/205kg |
|
Capping machine |
|
|
Model |
ZS-XG440D |
|
Working voltage |
AC220V/110V 50-60HZ |
|
Bottle height |
≤200mm |
|
Bottle caps diameter |
Customized |
|
Working speed |
20-30 bottles/minute(depending on bottle and caps) |
|
Working pressure |
0.4-0.6 MPa |
|
Conveyor size |
100mm(W)*1950mm(L) |
|
Package size |
About 2000*820*1800mm |
|
Net weight/Gross weight |
About 211kg/272kg |
|
Labeling Machine |
|
|
Model |
ZS-TB260R |
|
Power supply |
AC220V 50Hz/60Hz 1000W |
|
Working speed |
25-50 bottles/min(depends on bottle size) |
|
Labeling accuracy |
±1.0mm |
|
Applicable bottle diameter |
Φ12-100mm |
|
Applicable label size |
(L)20-300mm (H)15-150mm |
|
Label roll core diameter |
Φ76mm |
|
Label roll outer diameter |
Φ350mm |
|
Conveyor size |
112*2000mm(W) |
|
Machine size |
About (L)2000*(W)820*(H)1380(mm) |
|
Package size |
About (L)2100*(W)890*(H)1520(mm) |
|
Net weight/Gross weight |
About 180kg/About 250kg |
