ZONESUN ZS-AFC1Z Liquid Filling Capping Machine for Ink, Skincare, Eye Drops
The ZONESUN ZS-AFC1Z is an integrated liquid filling and capping solution featuring a hygienic peristaltic pump system. Designed to prevent product contamination by isolating the liquid from mechanical components, it ensures precise dosing and easy maintenance. Ideal for packaging small volumes of skincare products, eye drops, inks, and similar liquids. Its compact design and conveyor system support smooth, automated operation for light industrial production.
Specification
Model ZS-AFC1Z
Machine Voltage & Power 110V / 220V, 50–60Hz, 500W
Pump Type Peristaltic pump
Suitable Bottle Diameter 10–40mm
Filling Range ≤100ml
Bottle Height ≤120mm (customizable for taller bottles)
Cap Diameter Customized
Filling Nozzle Size Customized
Working Speed 20–50 bottles/min (depends on liquid & bottle size)
Conveyor Belt Size Approx. 670 × 80mm
Package Size Approx. 1200 × 700 × 1100mm
Package Weight Approx. 128kg
The ZONESUN ZS-AFC1Z is an integrated liquid filling and capping solution featuring a hygienic peristaltic pump system. Designed to prevent product contamination by isolating the liquid from mechanical components, it ensures precise dosing and easy maintenance. Ideal for packaging small volumes of skincare products, eye drops, inks, and similar liquids. Its compact design and conveyor system support smooth, automated operation for light industrial production.
Specification
Model ZS-AFC1Z
Machine Voltage & Power 110V / 220V, 50–60Hz, 500W
Pump Type Peristaltic pump
Suitable Bottle Diameter 10–40mm
Filling Range ≤100ml
Bottle Height ≤120mm (customizable for taller bottles)
Cap Diameter Customized
Filling Nozzle Size Customized
Working Speed 20–50 bottles/min (depends on liquid & bottle size)
Conveyor Belt Size Approx. 670 × 80mm
Package Size Approx. 1200 × 700 × 1100mm
Package Weight Approx. 128kg
Select Voltage
From $1,469.70
Original: $4,899.00
-70%ZONESUN ZS-AFC1Z Liquid Filling Capping Machine for Ink, Skincare, Eye Drops—
$4,899.00
$1,469.70
