ZONESUN ZS-GY1C Pneumatic Automatic Paste Filling Machine With Conveyor
Application
This automatic filling machine can be used for filling paste and liquid, such as cream, honey, chocolate, perfume, beverage, etc. Equipped with conveyor, it can greatly improve work efficiency. The machine can be widely used in food, beverage, cosmetic, daily chemical, medicine industries.
Notice
This machine can be customized according to customers' needs. And it can work with labeling machines and capping machines. If you need, please contact us. Thank you!
Product Information Specification
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Designed with touch screen control panel,the visual parameter makes it easier to set working data.It is set into English version,but we can customize different language if you need this.
The filling nozzle is with anti-dripping design,and it is also equipped with electric eyes to detect the passing by bottles,prevent from missing any bottles,ensure the filling accuracy.
The filling speed and waiting time can be adjusted ,rotate screws clockwise to slow down working speed. If you use the automatic working mode,please lengthen the waiting time to make the machine works better.The larger rotary knob on the right side is designed for controlling the filling range,make it easier to operate and adjust the machine.
It is equipped with the conveyor belt which is suitable for realizing automated production.It can work with automatic capping machine and labeling machine to help you improve working efficiency.
Application
This automatic filling machine can be used for filling paste and liquid, such as cream, honey, chocolate, perfume, beverage, etc. Equipped with conveyor, it can greatly improve work efficiency. The machine can be widely used in food, beverage, cosmetic, daily chemical, medicine industries.
Notice
This machine can be customized according to customers' needs. And it can work with labeling machines and capping machines. If you need, please contact us. Thank you!
Product Information Specification
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Designed with touch screen control panel,the visual parameter makes it easier to set working data.It is set into English version,but we can customize different language if you need this.
The filling nozzle is with anti-dripping design,and it is also equipped with electric eyes to detect the passing by bottles,prevent from missing any bottles,ensure the filling accuracy.
The filling speed and waiting time can be adjusted ,rotate screws clockwise to slow down working speed. If you use the automatic working mode,please lengthen the waiting time to make the machine works better.The larger rotary knob on the right side is designed for controlling the filling range,make it easier to operate and adjust the machine.
It is equipped with the conveyor belt which is suitable for realizing automated production.It can work with automatic capping machine and labeling machine to help you improve working efficiency.
Select Filling Range
Select Voltage
From $795.00
Original: $2,650.00
-70%ZONESUN ZS-GY1C Pneumatic Automatic Paste Filling Machine With Conveyor—
$2,650.00
$795.00Description
Application
This automatic filling machine can be used for filling paste and liquid, such as cream, honey, chocolate, perfume, beverage, etc. Equipped with conveyor, it can greatly improve work efficiency. The machine can be widely used in food, beverage, cosmetic, daily chemical, medicine industries.
Notice
This machine can be customized according to customers' needs. And it can work with labeling machines and capping machines. If you need, please contact us. Thank you!
Product Information Specification
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Model ZS-GY1C
Voltage Supply 220/110V, 50/60Hz
Power 130W
Filling Accuracy ≤±0.5%
Filling Speed 10–20 bottles/min
Filling Volume 5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml (select as needed)
Conveyor Size 2 m × 10 cm (L×W)
Filling Nozzle Size Φ10 mm
Equipped Air Pressure 0.4–0.6 MPa
Air Compressor Connector Size OD 8 mm
Air Consumption ≥0.1 m³/min
Designed with touch screen control panel,the visual parameter makes it easier to set working data.It is set into English version,but we can customize different language if you need this.
The filling nozzle is with anti-dripping design,and it is also equipped with electric eyes to detect the passing by bottles,prevent from missing any bottles,ensure the filling accuracy.
The filling speed and waiting time can be adjusted ,rotate screws clockwise to slow down working speed. If you use the automatic working mode,please lengthen the waiting time to make the machine works better.The larger rotary knob on the right side is designed for controlling the filling range,make it easier to operate and adjust the machine.
It is equipped with the conveyor belt which is suitable for realizing automated production.It can work with automatic capping machine and labeling machine to help you improve working efficiency.
